Lift A Whip recommends using a qualified auto electrician to instal this unit. Lift A Whip and staff will not be held responsible for any failures caused by an incorrect instalation.
Choose the desired mounting location of the unit and secure the Lift A Whip to vehicle with supplied bolts, choose suitable mounting location for switch.
Use a double pole double throw (DPDT) switch for this installation, the centre 2 pins are for your 12v or 24v feed, please make sure there is a 10-amp fuse inline from the power source to the switch then connect as shown in photo.
Connect the wiring to the Lift a Whip to the 4 remaining pins connecting the diagonally opposite pins together to allow for the polarity to reverse when switched. As shown in the picture.
Join the 2 positive wires together and the 2 negative wires together from the top and bottom wires on the switch with crimp terminals, as shown in photo.
Join the wires from the switch to the 2 wires on the actuator pos to pos neg to neg . I suggest crimp terminals, solder and heat shrink all joins/terminals. The actuator has its own built in limit switch and will cut out at full range of motion up or down.
Test your unit, and please send us pics and videos too share on our social media and follow us on Instagram, Facebook.
Thank you for supporting our small family business, our while family very much appreciate your support.
Aftermarket aerial erector, Designed to raise and lower your aerial without leaving the drivers seat.
